Intelligent online conductivity analyzer uses a highly responsive conductivity cell combined with a smart controller to deliver reliable and accurate conductivity monitoring for a wide range of water systems — including wastewater, industrial process water, boiler water, and purified water. With dual measurement ranges, multiple output options, and IP65-rated housing, it is an ideal choice for integration into modern automated systems.
|
| Intelligent Online Conductivity Analyzer |
Main Features
Measuring Ranges:
0–2000 μS/cm (for pure or soft water)
0–20000 μS/cm (for wastewater or process water)
Accuracy: ±1% Full Scale
Resolution: 1 μS/cm
Output Signals:
1 × 4–20 mA analog output (load <750Ω)
Optional RS485 digital output (ModBus protocol)
Control Function: 2 × Relay outputs (220V/1A)
Power Supply: 220VAC or 24VDC
Ingress Protection: IP65, suitable for industrial environments
Installation: Panel mount
Instrument Size: 96 × 96 × 143 mm
Cutout Size: 92 × 92 mm
Sensor Specifications
Measuring Principle: Conductivity cell method
Cell Constants: 0.01 / 0.1 / 1.0 (selectable)
Pressure Rating: 0.3 MPa (Max: 0.6 MPa)
Temperature Range: 0–100℃
Electrode Size: φ14 mm × L60 mm
Conductor Material: Stainless steel
Housing Material: Stainless steel
Connection Type: G3/4 thread (top & bottom)
Cable Length: 10 meters (customizable)
Application Environment: Suitable for wastewater, power plant water, process water, cooling water, etc.
 |  |  |
Industrial Wastewater Treatment Monitoring
Conductivity Control of Boiler/Condensate Water in Power Plants
Conductivity Monitoring of Pure Water in Food, Beverage, and Pharmaceutical Industries
Water Quality Control in Chemical Processes
Conductivity Assessment of Tap Water and Groundwater
 |  |  |  |
| Water & Wastewater Treatment | Food & Beverage | Chemical Industry | Pharmaceutical |
20+ Global Certifications: CE, IECEx, SIL 2/3, API 670, and ISO 9001 compliance.
48-Hour Emergency Support: Worldwide technical response network.
Multilingual Engineering Teams: Fluent in EN/JP for seamless collaboration.
Extreme Environment Expertise: -200°C to 3000°C measurement solutions.
High-Performance Materials: Hastelloy C276.
Custom OEM/ODM Services: Rapid prototyping in 72 hours.
 |  |  |  |
 |  |  |  |
