The MSS-750 digital smart SS (Suspended Solids) sensor utilizes the scattered light measurement principle. The measurement circuit is embedded inside the sensor housing, directly converting the raw signal into a standard digital output. It is unaffected by ambient light, features automatic cleaning, and requires low maintenance. It delivers stable, sensitive, and highly repeatable suspended solids analysis results, making full use of digital sensor advantages. It is an ideal choice for water quality monitoring in surface water, wastewater, and similar environments.
|
| Digital Smart SS Sensor (Suspended Solids) |
Technical Specifications
Measuring Range: 0–100/1000 mg/L
Resolution: 0.01 mg/L
Accuracy: <1%FS
Stability: ±1%FS/Y
Temperature Compensation: 18B20
pH Compensation: Glass pH electrode (optional)
Temperature Drift: ±0.1%FS/°C (within compensation range)
Response Time: ≥90% within 30 seconds
Power Supply: 12–24VDC
Power Consumption: <1W
Output Signal: RS485 (Standard Modbus RTU Protocol)
Polling Interval: ≥50ms
Operating Conditions: Medium temperature 0–60°C
Dimensions: φ37×200mm
Connection Thread: 3/4NPT
Housing Material: POM (customizable upon request)
Weight: approx. 260g
Protection Rating: IP68
Cable Length: Standard 5m (customizable)
Municipal and industrial wastewater treatment
Surface water and environmental monitoring
Chemical and pharmaceutical industries
Food and beverage processing
Aquaculture water quality management
 |  |  |  |
| Water & Wastewater Treatment | Chemical Industry | Food & beverage processing | Pharmaceutical |
