| Digital Intelligent TDS Electrode |
Technical Specifications
Measurement Range: 0–1000/10000 mg/L
Resolution: 0.01 mg/L
Accuracy: <1% FS
Stability: ±1% FS/year
Temperature Compensation: 18B20
Temperature Drift: ±0.1% FS/°C (within compensation range)
Response Time: ≥90% within 30 seconds
Power Supply: 12–24 VDC
Power Consumption: <1 W
Output Signal: RS485 (Standard Modbus RTU Protocol)
Polling Interval: ≥50 ms
Operating Temperature: 0–60°C
Dimensions: φ37 × 200 mm
Thread Connection: 3/4 NPT
Housing Material: POM (customizable)
Weight: Approx. 260 g
Protection Rating: IP68
Cable Length: Standard 5 m (customizable upon request)
Municipal and industrial wastewater treatment
Surface water and environmental monitoring
Chemical and pharmaceutical industries
Food and beverage processing
Aquaculture water quality management
 |  |  |  |
 |  |  |  |
