Nominal diameter (mm): DN01,DN02,DN03,DN04,DN08,DN15,DN20,DN25,DN40,DN50,DN80,DN100,DN150,DN200,DN250.
Not affected by physical properties such as viscosity and density of liquid.
Integrated design, small size, easily installed.
Application
It is suitable for trade handover and process control of loading and unloading materials in petrochemical, metallurgical, electric power, paper making, semiconductor, etc.
| Model | Nominal diameter | Medium temp. | Max.W.P | Max. flow-rate | ||
inch | mm | kg/min | Lb/min | |||
CMASS001 | 1/12” | DN01 | -50℃～+150℃ | ≤ 10MPa | 0.2 | 0.44 |
CMASS002 | 1/10” | DN02 | -50℃～+150℃ | ≤10MPa | 1.6 | 3.53 |
CMASS003 | 1/8” | DN03 | -50℃～+150℃ | ≤10MPa | 3 | 6.61 |
CMASS004 | 1/6” | DN04 | -50℃～+150℃ | ≤10MPa | 5 | 11 |
CMASS008 | 1/4” | DN08 | -50℃～+150℃ | ≤10MPa | 20 | 44 |
CMASS015 | 1/2” | DN15 | -50℃～+150℃ | ≤10MPa | 60 | 132 |
CMASS020 | 3/4” | DN20 | -50℃～+150℃ | ≤10MPa | 100 | 220 |
CMASS025 | 1” | DN25 | -50℃～+150℃ | ≤10MPa | 200 | 440 |
CMASS040 | 1-1/2” | DN40 | -50℃～+150℃ | ≤10MPa | 450 | 992 |
CMASS050 | 2” | DN50 | -50℃～+150℃ | ≤10MPa | 650 | 1433 |
CMASS080 | 3” | DN80 | -50℃～+150℃ | ≤6.3MPa | 2000 | 4409 |
CMASS100 | 4” | DN100 | -50℃～+150℃ | ≤4MPa | 3000 | 6613 |
CMASS150 | 6” | DN150 | -50℃～+150℃ | ≤4MPa | 12000 | 26455 |
CMASS200 | 8” | DN200 | -50℃～+150℃ | ≤4MPa | 18000 | 39683 |
CMASS250 | 10” | DN250 | -50℃～+150℃ | ≤4MPa | 29000 | 63934 |
 |  |  |  |
 |  |  |  |
