The MCS-750 Digital Intelligent Residual Chlorine Electrode is based on an industrial-grade online constant voltage residual chlorine electrode with a dual platinum ring structure. The measurement circuit is integrated within the sensor housing, and the original signal is directly converted into a standard digital signal output. It features both pH and temperature compensation functions, and delivers stable, sensitive, and highly repeatable residual chlorine measurement results. Fully leveraging the technical advantages of digital sensors, it is an ideal solution for water quality monitoring applications.
|
| Digital Intelligent Residual Chlorine Electrode |
Technical Specifications
Measuring range: 0-20mg/L; 0-20ppm
Resolution: 0.01mg/L; 0.01ppm
Accuracy: <1%FS
Stability: ±1%FS/Y
Temperature compensation: 18B20
pH compensation: pH glass electrode (optional)
Temperature drift: ±0.1%FS/°C (within compensation range)
Response time: ≥90% within 30 seconds
Power supply: 12-24VDC
Power consumption: <1W
Output signal: RS485 (Standard Modbus RTU protocol)
Polling interval: ≥50ms
Operating conditions: Medium temperature 0-60°C
Dimensions: φ37×200mm
Thread connection: 3/4NPT
Housing material: POM, customizable
Weight: Approx. 260g
Protection grade: IP68
Cable length: Standard 5m (customizable)
Municipal and industrial wastewater treatment
Surface water and environmental monitoring
Chemical and pharmaceutical industries
Food and beverage processing
Aquaculture water quality management
 |  |  |  |
| wastewater treatment | Chemical Industry | Pharmaceutica | Food & Beverage |
