The MES-750 digital intelligent conductivity electrode is based on an industrial inline conductivity electrode, with the measurement circuit integrated within the sensor housing. The raw signal is directly converted into a standard digital output. By incorporating our patented technology (Patent No. ZL201721755809.0), the sensor effectively prevents electrode polarization, delivering stable, sensitive, and highly repeatable conductivity analysis results. It fully leverages the technical advantages of digital sensors, making it an ideal choice for water quality monitoring applications.
|
| Digital Intelligent Conductivity Electrode |
Technical Specifications
Measurement Range: 0–2000/20000 μS/c
Resolution: 1 μS/cm
Accuracy: <1% FS
Stability: ±1% FS/year
Temperature Compensation: 18B20
Temperature Drift: ±0.1% FS/°C (within compensation range)
Response Time: ≥90% within 30 seconds
Power Supply: 12–24 VDC
Power Consumption: <1 W
Output Signal: RS485 (Standard Modbus RTU Protocol)
Polling Interval: ≥50 ms
Operating Temperature: 0–60°C
Dimensions: φ37 × 200 mm
Thread Connection: 3/4 NPT
Housing Material: POM (customizable)
Municipal and industrial wastewater treatment
Surface water and environmental monitoring
Chemical and pharmaceutical industries
Food and beverage processing
Aquaculture water quality management
 |  |  |  |
| Water & Wastewater Treatment | Pharmaceutical | Chemical Industry | Food & Beverage |
