Nominal diameter (mm): DN01,DN02,DN03,DN04,DN08,DN15,DN25.
Excellent performance of small flow rate measurement, meet fuelling or measuring demand for hydrogen and other high pressure gas.
Have done the test at 1.5 times of the rated pressure, to ensure reliability and security under super pressure.
Smooth tube without other components. There is no additional pressure loss during measuring process.
The components of contacting medium are made of composite metal materials with excellent resistant performance to hydrogen embrittlement.
Application
It is suitable for high pressure gas metering, hydrogen/CNG metering platforms, etc.
Model | A | B | C | Max.W.P | M |
CMASS003 | 207 | 348 | 180 | ≤45MPa | NPT 1/4” Female thread |
CMASS004 | 207 | 348 | 180 | ≤30MPa | NPT 1/4” Female thread |
CMASS008 | 218 | 325 | 157 | ≤45MPa | 13/16-16UNF Female thread |
≤30MPa | |||||
CMASS015 | 206 | 348 | 180 | ≤30MPa | G3/4” Female thread |
